Product Details:
Payment & Shipping Terms:
|
Wavelength: | 650nm | Output Power: | <5mw |
---|---|---|---|
Circuit Control: | ACC Line | Operating Voltage: | DC 3V |
Working Current: | < 35mA |
Such kind of products can be widely used for electrical tools, leveling instrument, orientator, range finder, laser swinger, laser level. We can provide photoelectric solutions for customers and can help design laser module to meet customers’ requirement.
Specifications:
Output Wavelength: 650nm
Output Power: <5mw
Circuit Control: ACC Line
Operating Voltage: DC 3V
Working Current: < 35mA
Warm-up Time: No
Working Temperature: -10℃~+40℃
Storage Temperature: +10℃~+40℃
Dimension: 10.5mm (dia)*29mm(L)
Structure Features: Laser Diode + Lenses
Remarks: Red line is Positive ,Black line is Negative.
