660nm 200mw Red Dot Beam Laser Module with 5V Power Supply For Electrical Tools And Leveling Instrument

Large Image : 660nm 200mw Red Dot Beam Laser Module with 5V Power Supply For Electrical Tools And Leveling Instrument

Product Details:

Place of Origin:	China
Certification:	CE , Rohs
Model Number:	GS-660AD200

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	31.6USD
Packaging Details:	first in anti-static bag then in carton
Delivery Time:	3-5 days for sample order or according to your order quantity
Payment Terms:	Paypal , Western Union ,T/T , Moneygram
Supply Ability:	10000pcs/month

Contact Now

Detailed Product Description

Wavelength:	660nm±10nm	Output Power:	200-230mw
Beam Type:	Dot	Circuit Control:	ACC Line

Such kind of products can be widely used for electrical tools, leveling instrument, orientator, range finder, laser swinger, laser level. We can provide photoelectric solutions for customers and can help design laser module to meet customers’ requirement.

Specifications:

Wavelength: 660nm±10nm
Output Power: 200-230mW
Surface Treatment: Anode fuchsia
Housing Material: Aviation Aluminium
Circuit Control: ACC Line
Anti-access Protection: Yes
Operating Voltage: DC=3-5V
Working Current: I < 320mA
Warm-up Time: No
Working Temperature: -10℃~+40℃
Storage Temperature: +10℃~+40℃

Dimension: 20mm (dia)*58mm(L)
Structure Features: Laser Diode + Lenses + Radiating Shell

Remarks: red line is positive ,black line is negative ,end power line is about 100cm long.
