660nm 200mw Red Dot Beam Laser Module For Electrical Tools And Leveling Instrument
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Wavelength: | 660nm±10mm | Output Power: | 200-230mw |
|---|---|---|---|
| Circuit Control: | ACC Line | Operating Voltage: | DC 3-5V |
| Working Current: | < 320mA |
|
Such kind of products can be widely used for electrical tools, leveling instrument, orientator, range finder, laser swinger, laser level. We can provide photoelectric solutions for customers and can help design laser module to meet customers’ requirement.
Specifications:
Wavelength: 660nm±10mm Output Power: 200-230mw Surface Treatment: Anode Black/Army Green Housing Material : Aviation Aluminium Circuit Control: ACC Line Anti-access Protection: Yes Operating Voltage: DC 3-5V Working Current: < 320mA Warm-up Time: No Storage Temperature: +10℃~+40℃ Dimension: 14.5mm (dia)*45mm(L) Structure Features: Laser Diode + Lenses + Transformer
Remarks: Orange line is Positive ,White line is Negative. |
 |
