Wavelength: | 445nm | Output Power: | 1000mw |
---|---|---|---|
Perating Voltage: | DC 12V | Operating Current: | <1000mA |
BeamType: | Dot |
Such kind of products can be widely used for electrical tools, leveling instrument, orientator, range finder, laser swinger, laser level. We can provide photoelectric solutions for customers and can help design laser module to meet customers' requirement.
Specification :
Wavelength: 445nm
Output power: 1000mw
Operating voltage: DC12V
Operating current: <1000mA
Laser dimension: 66*31.8*32mm
Driver board dimension: 72*36*12mm
Beam mode: Dot
Modulation frequency: 0-20KHZ
Modulation mode: square wave TTL OV OFF 2.5-5V ON
Operating temperature: -10℃---40℃
Storage temperature: -40℃---80℃
Power supply: Input:110-240V AC, output:12V DC
