445nm 1.5W Blue Laser Module With TTL Modulation For Laser Stage Light
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Wavelength: | 445nm | Output Power: | 1.3-1.5W |
|---|---|---|---|
| Cooling Method: | Aluminum Radiator | Material: | Aluminium |
| Operating Voltage: | 12V | Working Current: | < 1.6A |
Such kind of products can be widely used for stage laser light, TTL modulation, can work for a long time ,it is a real industrial laser .We can provide photoelectric solutions for customers and can help design laser module to meet customers requirement.
Specifications:
Mainframe Dimension: 69mm (L)*30mm(W)*30mm(H)
Power Supply Dimension: 47.5mm (L)*31.5mm(W)*16mm(H)
Wavelength: 445nm
Output Power: 1.3-1.5W
Cooling Method: Aluminum Radiator
Size of Light-spot: Adjustable Focusing
Performance Characteristic: Continuous Work
Surface Treatment: Blue
Material: Aluminium
Circuit Control: Constant Current
Anti-access Protection: Identify the Positive and Negative Automatic
Operating Voltage: 12V
Working Current: < 1.6A
Warm-up Time: No
Working Temperature: -10°c~+40°c
Storage Temperature: -10°c~+40°c
Structure Features: Laser Diode + Lenses + Radiating Shell
Remarks:Power Supply is extenal.
Warning: the input voltage is 12V, exceed 12V will cause the circuit and module damaged.
